| Output | 6.3 - 6.8 kW |
|---|---|
| rpm | 3000 - 3600 rpm |
| engine_common_iconlist | - |
- Vertical cylinder, 4-cycle, air-cooled diesel engine.
- L-Vseries meets EPA’s strict Tier 2.
- Compact, Direct injection Engine
= Easy installation & Low Fuel Consumption. - Low Vibration and Low Noise.
- Quick and Easy Start.
Specifications
| Models | L100V | ||
|---|---|---|---|
| No. of Cylinders | 1 | ||
| Bore x Stroke | mm | Φ86 x 75 | |
| Displacement | liter | 0.435 | |
| Maximum Rated Output |
Engine Speed | min-1(rpm) | 3000~3600 |
| Output | kW[hp] | 6.3~6.8 [8.5~9.3] | |
| Engine Dry mass | kg | 53.5 / 48.5 | |
| Dimensions | Length x Width x Height | mm | 412 x 471 x 494 |
