| LOADER ARMS | Vertical |
|---|---|
| OPERATING WEIGHT (OPEN ROPS BASE) | 4,175 kg |
| OPERATING WEIGHT (AWC CAB BASE) | 4,330 kg |
| GROUND PRESSURE AT OPERATING WEIGHT | 42.0 kPa |
| RATED OPERATING CAPACITY (35% of tipping load) | 1,159 kg |
| TIPPING LOAD | 3,311 kg |
| TRAVEL SPEED, MAXIMUM | 12.1 kph |
| TYPE | Diesel 4-cylinder, Intercooled Turbo |
|---|---|
| MODEL | Yanmar 4TN86CHT |
| GROSS POWER RATING | 53.3 kW (71.5 hp) |
| DISPLACEMENT | 2.1 L |
| TORQUE, PEAK | 262.8 Nm |
| COOLING SYSTEM | Belt-driven fan and anti-freeze filled radiator cooling system |
| INTAKE AIR CLEANER | Dual-Stage |
| EMISSION CONTROLS | Meets all U.S. EPA Tier 4 final standards |
| TRACK WIDTH | 320 mm |
|---|---|
| LENGTH OF TRACK ON GROUND | 1,524 mm |
| GROUND CONTACT AREA | 0.98 m2 |
| DRIVE SYSTEM | Two hydrostatic direct drive sprockets controlled by single joystick |
| UNDERCARRIAGE SUSPENSION | Two independent torsion axles per undercarriage |
| PUMP CAPACITY | Low - 81 lpm High - 101 lpm |
|---|---|
| SYSTEM PRESSURE, MAX. | Low - 23,994 kPa High - 26,000 kPa |
| CONTROLS | Intermittent via joystick button or continuous via console switch |
| COUPLERS | Flat Faced Couplers: 1/2 in. |
| COOLING SYSTEM | High efficiency side-by-side radiator and oil cooler |
| NOMINAL CHARGE | 12 V |
|---|---|
| BATTERY | 800 CCA |
| CHARGING SYSTEM | 80 amp alternator |
| OUTLETS | 1-12 V port inside operator station |
| WIRING | Pre-wired for all factory-available accessories |
| STANDARD FEATURES | Block heater |
| FUEL TANK | 81 L |
|---|
| CAB | ROPS or All-Weather Cab with curved glass door |
|---|---|
| SEAT | Mechanical suspension seat with 2-in. seat belt |
| CONTROLS | Electronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speeds |
| ENGINE SPEED | Standard hand dial operation with foot pedal optional |
| 7-IN. COLOR MACHINE DISPLAY | Fuel, tachometer, engine temp, hour meter, battery, trip meter, hydraulic temperature, water temperature, multiple languages |
| ROPS | ROPS: ISO 3471 Restraint-ISO 6683, SAE J2292, Cal OSHA 1596 |
| FOPS | ISO 3449 Level 1(Level 2 optional), emergency roof exit |
| ILLUMINATION | 2 - Forward-facing LED lights 2 - Rear-facing LED lights |
| STANDARD FEATURES | Mechanical suspension seat, fixed joystick controls, 7-in. color display, roof panel, rear window, cupholder, two speed, standard flow |
| OPTIONAL FEATURES | All Weather Cab, heat & A/C, adjustable joystick controls, foot throttle, phone holder, radio with Bluetooth and USB, roof insulation, high flow, 3 in. seat belt, air ride seat, rotating magnetic beacon, LED side lights, backup camera, SmartAssist Remote telematics, 1/2 in. polycarbonate door, Hyd Q/A, attachment control kit, dual direction bucket positioning, return to position and ride control |
