Documents: Marine Commercial

Propulsion Engine(High Speed)

Propulsion diesel engines - Commercial series:

Model Rating Max Output
kW(mhp) $$/min-1
Marine gear model Catalog Operation manual Engines Operation Manual Gears Outline drawing
PDF DXF
4CHE3 M 57.4 (78)*/2550 Bobtail download download N/A download download
YX-30 - download download
6CHE3 M 84.6 (115)*/2550 Bobtail download N/A download download
YX-30 N/A download download
6CH-HTE3 M 125 (170)*/2550 Bobtail download N/A download download
YX-71 N/A download download
6CH-WUTE M 188 (255)*/2550 Bobtail download download N/A download download
YX-71 N/A download download
6LY2M-WDT L 243 (330) /3200 Bobtail download download N/A download download
YX-50S download download
6LY2M-WST L 277 (377) /3200 Bobtail download download
YX-50S download download
6CXBM-GT H 265 (360) /2400 Bobtail download download N/A download download
M 294 (400) /2500 YX-75 N/A download download
L 341 (464) /2700 YXH-130 download N/A download download
S 374 (509) /2700 - - - -
6HA2M-WHT H 204 (278) /1880 Bobtail download download N/A download download
M 257 (350) /1950 YX-120 N/A download download
YX-120L N/A download download
6HA2M-WDT M 298 (405) /1950 Bobtail download N/A download download
YX-120 N/A download download
YX-120L N/A download download
6HYM-WET H 368 (500) /1950 Bobtail download download N/A download download
M 441 (600) /2100 YX-160 download N/A download download
L 478 (650) /2150 YX-161L N/A download download
S 515 (700) /2200 - - - -
6AYM-WST H 485 (659) /1900 Bobtail download download N/A download download
YX-181 N/A download download
YX-180L N/A download download
YXH-240L N/A download download
6AYAM-ET Continuous 555 (755) /1900 Bobtail download N/A N/A download download
YXH240 N/A N/A N/A
YXH-240L N/A N/A N/A
6AYM-WET H 555 (755) /1840 Bobtail download download N/A download download
M 610 (829) /1900 YXH240 N/A download download
YXH-240L N/A download download
6AYM-WGT L 670 (911) /1938 Bobtail download N/A download download
YXH240 N/A download download
12AYM-WST H 882 (1200) /1850 Bobtail download download - download download
H 1030 (1400) /1900 -
12AYM-WET H 1140 (1550) /1840 Bobtail download - download download
M 1220 (1659) /1900 -
12AYM-WGT L 1340 (1822) /1940 Bobtail download - download download

* Output at prop shaft
$$ All output ratings as per ISO 3046-1 standard
Rating definition: Please refer respective catalogs
Marine class society approval: Please contact Yanmar for further information.

Full line up - Propulsion Engine (Medium Speed) / Auxiliary Engine

Propulsion Engine(Medium Speed) Specification List

Auxiliary Engine Specification List
